PRODUCT FUNCTION
-
High-frequency sampling
High-frequency electrical parameter collection, supporting overcurrent, overvoltage and undervoltage
-
Multi-channel monitoring
Supports 1 to 3 power fingerprint monitoring channels, with a current range of up to 120A
-
Safety protection
Overcurrent, overvoltage, undervoltage, phase loss, overload and other alarms, intelligently disting
-
Electric power monitoring
Real-time collection and analysis of key parameters of the power grid (such as voltage and power), a
-
High-frequency sampling
Support high-speed synchronous sampling of voltage, current, temperature and other data; Support sta
-
Electric energy metering
The bidirectional electric energy metering accuracy is grade 1 and supports fee control metering
Performance Parameter
Communication methodCommunication method
| Model | SMCT F3 | SMCT F5 |
| Function type | ||
| Type | Electric vehicle identification | Electrical fire monitoring |
| CT input interface | 3个 | 3个 |
| Circuit measurement | Three-channel current measurement with load identification | One current channel, one temperature channel, one leakage channel |
| Circuit measurement | ||
| Rated current In | 0~100A | 0~100A |
| Rated working voltage Ue | AC 230V | AC 230V |
| Network characteristics | ||
| Protocol type | MQTT | MQTT |
| 4G | 4G | |
| Support | Support | |
| Other features | ||
| Working environment temperature | -20℃~+80℃ | -20℃~+80℃ |
| Working relative humidity | ≤95%(No condensation) | ≤95%(No condensation) |
| Installation method | Standard guide rail installation | Standard guide rail installation |
Product Advantages
-
-
可扩展性强
模块化设计，支持算法升级，扩展新功能
-
-
功能全面
集多种监测、计量、通讯和报警功能于一体
-
-
稳定可靠
依托强大的云计算算法和先进的通信技术
-
-
智能化程度高
自动处理和分析数据，及时发现潜在问题并预警
-
-
安全保密
采用多重加密技术和严格的安全管理措施
-
-
体积小巧
集成度高，体积小巧，安装方便，成本低
Application Scenarios
-
Community
Monitoring of electric bike charging at homeElectrical fire hazard monitoringFire emergency intermodal monitoring -
School
Supervision of illegal electrical appliances in dormitoriesManagement of energy-saving electricity usage in public areasFire emergency protection in colleges and universities -
Commercial
Monitoring of safety hazards in commercial electricity usageRemote merchant electricity usage managementEnergy conservation in public areas of shopping malls -
Logistics
Energy conservation management for warehouse consumptionSafety charging monitoring for express delivery electric vehiclesCircuit aging safety warning -
Park
Energy conservation management in public areas of the parkEfficient and rapid power restoration and closingSafety monitoring of potential hazards -
Shop
Store electrical safety monitoringIdentification of high-power malignant loadsFire prevention and early warning management
